Asus KFN5-D SLI

108604 - Asus KFN5-D SLI Motherboard, Supports 2 AMD Opteron 2000 Series processors in the Dual Socket 1207, nVIDIA nForce Professional 3600 chipset, 2 x PCIe x16, 1 x PCIe x1, 1 x 32-bit 33MHz PCI, DDR2, Dual LAN, USB, IDE, SATA2, RAID, Audio, SPDIF, E-ATX Form Factor
Condition: New- Retail Box, Warranty: 1 year
by Asus
1 review | Add Your Review

$0.00

108604 - KFN5-D SLI
Asus KFN5-D SLI Motherboard, Supports 2 AMD Opteron 2000 Series processors in the Dual Socket 1207, nVIDIA nForce Professional 3600 chipset, 2 x PCIe x16, 1 x PCIe x1, 1 x 32-bit 33MHz PCI, DDR2, Dual LAN, USB, IDE, SATA2, RAID, Audio, SPDIF, E-ATX Form Factor

Asus KFN5-D SLI Motherboard

Asus KFN5-D SLI Motherboard

Supports 2 AMD Opteron 2000 Series processors in the Dual Socket 1207, nVIDIA nForce Professional 3600 chipset, 2 x PCIe x16, 1 x PCIe x1, 1 x 32-bit 33MHz PCI, DDR2, Dual LAN, USB, IDE, SATA2, RAID, Audio, SPDIF, E-ATX Form Factor

Asus KFN5-D SLI Motherboard, Supports 2 AMD Opteron 2000 Series processors in the Dual Socket 1207, nVIDIA nForce Professional 3600 chipset, 2 x PCIe x16, 1 x PCIe x1, 1 x 32-bit 33MHz PCI, DDR2, Dual LAN, USB, IDE, SATA2, RAID, Audio, SPDIF, E-ATX Form Factor

  • Internal I/O Interface:
    • 1 x Floppy connector
    • 3 x USB 2.0/1.1 headers
    • 6 x SATA2 ports
    • 1 x IDE Port
  • Rear Panel I/O Ports:
    • 1 x PS/2 Keyboard
    • 1 X PS/2 Mouse
    • 1 x S/PDIF out
    • 1 x LPT1 port
    • 1 x Serial port
    • 1 set 5.1 channel Audio Jack (3 jacks)
    • 4 x USB 2.0/1.1 ports
    • 2 x RJ 45 Port

  • On-Board LAN:
    • 2 x Broadcom® BCM5754 PCI-E Gb LAN

  • Power Connector :
    • SSI 24-pin
    • SSI 8-pin

Asus KFN5-D SLI Motherboard

  • Model:
    • Asus KFN5-D SLI Motherboard
  • Processor Support:
    • Supports 2 AMD Opteron 2000 Series processors Core Logic
    • Socket 1207

  • FSB:
    • 2000 MTS

  • Chipset:
    • nVIDIA nForce Professional 3600
  • Memory:
    • 8 x 240-pin DDR2 DIMM socket support up to 32 GB
    • Support Dual Channel DDR2 533/667/800 MHz
    • Memory Size: 512 MB, 1 GB, 2GB

  • Expansion Slots:
    • 2 x PCIe x16 (Support nVidia SLI Technology)
    • 1 x PCIe x1
    • 1 x PCI 32bit/33MHz slots

  • Storage:
    • 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
    • MCP55 Pro:
    • 6 x SATA2 3Gb/s
    • RAID 0, 1, 0+1, 5, JBOD
    • Silicon Image Sil3132:
    • 2 x SATA2 3Gb/s
    • RAID 0, RAID 1 configuration

  • Audio:
    • Integrated AC'97 Audio CODEC
    • 2/4/5.1
    • Compliant with HD specification

  • BIOS:
    • AMI BIOS 8 MB LPC
    • GREEN PnP, DMI, SMBIOS 2.3, ACPI 2.0a

  • Form Factor:
    • E-ATX Form Factor
    • 12 x 10.5 inch
