Asus M3A79-T DELUXE

110515 - Asus M3A79-T DELUXE Motherboard Supports AMD Phenom™ FX / Phenom™ / Athlon™ 64X2 / Athlon™ 64 FX / Sempron™ processor in the Socket AM2+, AMD 790FX chipset, 4 x PCI Express x16 ATI CrossFireX™, 2 x PCI 32-bit, DDR2, LAN, USB, IDE, SATA2, eSATA, RAID, Firewire, Audio, SPDIF, ATX Form Facto
Condition: New- Retail Box, Warranty: 1 year
by Asus
1 review | Add Your Review

$240.89

110515 - M3A79-T DELUXE
Asus M3A79-T DELUXE Motherboard Supports AMD Phenom™ FX / Phenom™ / Athlon™ 64X2 / Athlon™ 64 FX / Sempron™ processor in the Socket AM2+, AMD 790FX chipset, 4 x PCI Express x16 ATI CrossFireX™, 2 x PCI 32-bit, DDR2, LAN, USB, IDE, SATA2, eSATA, RAID, Firewire, Audio, SPDIF, ATX Form Facto

Asus M3A79-T DELUXE Motherboard

Asus M3A79-T DELUXE Motherboard

Supports AMD Phenom FX / Phenom / Athlon 64X2 / Athlon 64 FX / Sempron processor in the Socket AM2+, AMD 790FX chipset, 4 x PCI Express x16 ATI CrossFireX, 2 x PCI 32-bit, DDR2, LAN, USB, IDE, SATA2, eSATA, RAID, Firewire, Audio, SPDIF, ATX Form Factor

Asus M3A79-T DELUXE Motherboard Supports AMD Phenom™ FX / Phenom™ / Athlon™ 64X2 / Athlon™ 64 FX / Sempron™ processor in the Socket AM2+, AMD 790FX chipset, 4 x PCI Express x16 ATI CrossFireX™, 2 x PCI 32-bit, DDR2, LAN, USB, IDE, SATA2, eSATA, RAID, Firewire, Audio, SPDIF, ATX Form Factor

  • Internal I/O Interface:
    • 1 x Floppy connector
    • 3 x USB 2.0/1.1 headers
    • 1 x IEEE1394a connector
    • 1 x S/PDIF output connector
    • 1 x COM connector
    • 6 x SATA2 ports
    • 1 x IDE Port
  • Rear Panel I/O Ports:
    • 1 x PS/2 Keyboard / Mouse combo port
    • 1 x Optical + 1 x Coaxial S/PDIF Out ports
    • 1 x IEEE 1394a
    • 1 x External SATA port
    • 1 set 7.1 channel Audio Jack (6 jacks)
    • 6 x USB 2.0/1.1 ports
    • 1 x RJ 45 Port

  • On-Board LAN:
    • Marvell® 88E8056 Gigabit LAN controller featuring AI NET 2

  • Power Connector :
    • 1 x 24pin main power
    • 1 x 8-pin ATX 12V Power connector

  • Firewire:
    • LSI® L-FW3227 controller supports 2 x 1394a ports (1 at mid-board; 1 at back panel)

Asus M3A79-T DELUXE Motherboard

  • Model:
    • Asus M3A79-T DELUXE Motherboard
  • Processor Support:
    • Supports AMD Phenom FX / Phenom / Athlon 64x2 / Athlon 64FX / Sempron
    • Support up to 140W CPU
    • AMD Cool 'n' Quiet Technology
    • Socket AM2+

  • FSB:
    • Up to 5200/MT/s HyperTransport 3.0 interface for AM2+ CPU
    • 2000 / 1600 MT/s for AM2 CPU

  • Chipset:
    • AMD 790FX
  • Memory:
    • 4 x 240-pin DDR2 DIMM socket support up to 16 GB
    • Support Dual Channel DDR2 1066/800/667 Mhz
    • ECC and non-ECC, un-buffered
    • DDR2 1066 is supported by AM2+ CPU only

  • Expansion Slots:
    • 4 x PCIe 2.0 x16 slots with ATI CrossFireX support (@ dual x16, triple x16 / x8 / x8, or quad x8 modes)
    • 2 x PCI 32 Bits 2.2
    • Supports ATI CrossFireX graphics cards; up to Quad CrossFireX

  • Audio:
    • ADI® AD2000B 8 -Channel High Definition Audio CODEC
    • - Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking
    • - Coaxial / Optical S/PDIF Out ports at back I/O

  • Storage:
    • 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
    • 6 xSATA 3 Gb/s ports Support RAID 0,1,5,10
    • Marvell® 88SE6111 SATA controller
    • 1 x External SATA 3Gb/s port (SATA On-the-Go)

  • BIOS:
    • 8Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0, ACPI 2.0a, SM BIOS 2.5,
    • WOL by PME, WOR by PME, WOR by Ring, Chasis Intrusion, PXE

  • Form Factor:
    • ATX Form Factor, 12 inch x 9.6 inch ( 30.5 cm x24.4 cm )
