Asus F2A55-M LE

112987 - ASUS F2A55-M LE Motherboard, Supports AMD Socket FM2 Athlon/A- Series Processors, 1 PCI Slot, 1 PCI Slot X1, 2 PCI Express x16 slots, Support for SATA3, Raid, VGA Port, DVI-D Port, HDMI Port, DDR3 RAM, On Board Audio, Video, LAN, 12 USB ports, Micro ATX form Factor.
Condition: New, Warranty: 1 year
by Asus
1 review | Add Your Review

$104.38

112987 - F2A55-M LE
ASUS F2A55-M LE Motherboard, Supports AMD Socket FM2 Athlon/A- Series Processors, 1 PCI Slot, 1 PCI Slot X1, 2 PCI Express x16 slots, Support for SATA3, Raid, VGA Port, DVI-D Port, HDMI Port, DDR3 RAM, On Board Audio, Video, LAN, 12 USB ports, Micro ATX form Factor.

ASUS F2A55-M LE Motherboard. Specifications, price and availability

ASUS F2A55-M LE Motherboard

ASUS F2A55-M LE Motherboard, Supports AMD Socket FM2 Athlon/A- Series Processors, 1 PCI Slot, 1 PCI Slot X1, 2 PCI Express x16 slots, Support for SATA3, Raid, VGA Port, DVI-D Port, HDMI Port, DDR3 RAM, On Board Audio, Video, LAN, 12 USB ports, Micro ATX form Factor.



ASUS F2A55-M LE Motherboard

ASUS F2A55-M LE Motherboard

  • Rear Panel I/O Ports:
    • 1 x PS/2 keyboard/mouse combo port(s)
    • 1 x DVI
    • 1 x D-Sub
    • 1 x HDMI
    • 1 x LAN (RJ45) port(s)
    • 6 x USB 2.0
    • 1 x Optical S/PDIF out
    • 3 x Audio jack(s)
  • Internal I/O Interface:
    • 3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)
    • 1 x COM port(s) connector(s)
    • 6 x SATA 3Gb/s connector(s)
    • 1 x CPU Fan connector(s) (4 -pin)
    • 1 x Chassis Fan connector(s) (4 -pin)
    • 1 x Power Fan connector(s) (3 -pin)
    • 1 x S/PDIF out header(s)
    • 1 x 24-pin EATX Power connector(s)
    • 1 x 4-pin ATX 12V Power connector(s)
    • 1 x Front panel audio connector(s) (AAFP)
    • 1 x System panel(s)
  • USB Ports:
    • AMD A55 FCH (Hudson D2) chipset :
    • 12 x USB 2.0 port(s) (6 at back panel, , 6 at mid-board)
  • Over clocking Features:
    • Overclocking Protection :
    • ASUS C.P.R.(CPU Parameter Recall)
  • Accessories:
    • User's manual
    • I/O Shield
    • 2 x SATA 3Gb/s cable(s)
  • On-Board LAN:
    • Realtek ® 8111F, 1 x Gigabit LAN Controller(s)
  • BIOS:
    • 64 Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS V2.7, ACPI V2.0a
  • Support Disc:
    • Drivers, ASUS utilities, ASUS Update, Anti-virus software (OEM version)







Motherboard Specifications

  • Model:
    • ASUS F2A55-M LE Motherboard
  • CPU:
    • AMD Socket FM2 Athlon/A- Series Processors
    • Supports CPU up to 4 cores
    • Supports AMD ® Turbo Core 3.0 Technology
  • Chipset:
    • AMD A55 FCH (Hudson D2)
  • Memory:
    • 2 x DIMM, Max. 32GB, DDR3 1866/1600/1333/1066/667 MHz Non-ECC, Un-buffered Memory
    • Dual Channel Memory Architecture
      * The Max. 32GB memory capacity can be supported with DIMMs of 16GB (or above). ASUS will update QVL once the DIMMs are available on the market.
      * Refer to www.asus.com or user manual for the Memory QVL (Qualified Vendors Lists).
      * Due to OS limitation, when installing total memory of 4GB capacity or more, Windows ® 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows ® OS when you want to install 4GB or more memory on the motherboard.
  • Expansion Slots:
    • 2 x PCIe 2.0 x16 (x16/x4)
    • 1 x PCIe 2.0 x1
    • 1 x PCI
  • On-Board Audio:
    • Realtek ® ALC887 8-Channel High Definition Audio CODEC
    • Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
  • On-Board Video:
    • Integrated AMD Radeon HD 7000 Series Graphics in A-series APU
    • Multi-VGA output support : HDMI/DVI/RGB ports
    • Supports HDMI with max. resolution 1920 x 1080 @ 60 Hz
    • Supports DVI with max. resolution 2560 x 1600 @ 60 Hz
    • Supports RGB with max. resolution 1920 x 1600 @ 60 Hz
    • Maximum shared memory of 2048 MB
    • AMD ® Dual Graphics technology support *1
    • Supports DirectX 11
  • Storage:
    • 6 x SATA 3Gb/s port(s), blue
    • Support Raid 0, 1, 10, JBOD
  • Special Features:
    • ASUS EPU :
      EPU
    • ASUS Digital Power Design :
      Industry leading Digital 3 +2 Phase Power Design
      ASUS DIGI+ VRM Utility
    • TurboV
    • GPU Boost
    • ASUS Exclusive Features :
      AI Suite II
      Ai Charger
      Anti-Surge
      ESD Guards
      ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
      Network iControl
      Disk Unlocker
    • ASUS Quiet Thermal Solution :
      Stylish Fanless Design Heat-sink solution
      ASUS Fan Xpert
    • ASUS EZ DIY :
      ASUS CrashFree BIOS 3
      ASUS EZ Flash 2
      ASUS MyLogo 2

  • Form Factor:
    • mATX Form Factor
    • 9.6 inch x 9.2 inch ( 24.4 cm x 23.4 cm )
