asRock P5B-DE

113706 - Intel Socket LGA775 Motherboard, with 1 PCI-e x16 Slot/2 PCI-e x1 Slots/3 PCI Slots, on board audio, video and LAN, 6 USB Ports, 4 SATA Ports, 4 DIMM Slots and ATX Form Factor
Condition: New, Warranty: 1 year
by asRock
1 review | Add Your Review

$0.00

113706 - P5B-DE
Intel Socket LGA775 Motherboard, with 1 PCI-e x16 Slot/2 PCI-e x1 Slots/3 PCI Slots, on board audio, video and LAN, 6 USB Ports, 4 SATA Ports, 4 DIMM Slots and ATX Form Factor

asRock P5B-DE Motherboard. Specifications, price and availability

asRock P5B-DE Motherboard

Intel Socket LGA775 Motherboard, with 1 PCI-e x16 Slot/2 PCI-e x1 Slots/3 PCI Slots, on board audio, video and LAN, 6 USB Ports, 4 SATA Ports, 4 DIMM Slots and ATX Form Factor



asRock P5B-DE Motherboard

asRock P5B-DE Motherboard

  • Storage:
    •  4 x SATA2 3.0 Gb/s connectors (No support for RAID and "Hot Plug" functions)
  • Rear Panel I/O Ports:
    • 1 x PS/2 Mouse Port
    • 1 x PS/2 Keyboard Port
    • 1 x IEEE 1394 Port
    • 6 x Ready-to-Use USB 2.0 Ports
    • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
    • HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
  • Internal I/O Interface:
    •  4 x SATA2 3.0 Gb/s connectors (No support for RAID and "Hot Plug" functions)
    •  1 x ATA133 IDE connector (supports 2 x IDE devices)
    •  1 x Floppy connector
    •  1 x Print port header
    •  1 x COM port header
    •  1 x HDMI_SPDIF header
    •  CPU/Chassis/Power FAN connector
    •  24 pin ATX power connector
    •  8 pin 12V power connector
    •  CD in header
    •  Front panel audio connector
    •  2 x USB 2.0 headers (support 4 USB 2.0 ports)
  • Special Features:
    • ASRock OC Tuner
    •  Intelligent Energy Saver
    •  Instant Boot
    •  ASRock Instant Flash
    •  ASRock OC DNA
    •  Hybrid Booster:
    •  CPU Frequency Stepless Control
    •  ASRock U-COP
    •  Boot Failure Guard (B.F.G.)
    • Drivers, Utilities, AntiVirus Software (Trial Version)
    •  Microsoft ®  Windows ®  7 / 7 64-bit / Vista / Vista 64-bit / XP / XP 64-bit / 2000 compliant
    •  FCC, CE, WHQL


Motherboard Specifications

  • Model:
    • asRock P5B-DE Motherboard
  • Processor Support:
    •  LGA 775 for Intel ®  Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium ®  Dual Core / Celeron ®  Dual Core / Celeron, supporting Penryn Quad Core Yorkfield and Dual Core Wolfdale processors
    • Compatible with all FSB1333/1066/800/533 MHz CPUs
    • Supports Hyper-Threading Technology
    • Supports Untied Overclocking Technology
    • Supports EM64T CPU
  • Chipset:
    •  Northbridge: Intel ®  P965
    •  Southbridge: Intel ®  ICH8
  • Memory:
    •  Dual Channel DDR2 memory technology
    •  4 x DDR2 DIMM slots
    •  Supports DDR2 800/667/533 non-ECC, un-buffered memory
    •  Max. capacity of system memory: 8GB*
  • Expansion Slots:
    •  1 x PCI Express x16 slot
    •  2 x PCI Express x1 slots
    •  3 x PCI slots
  • On-Board Audio:
    • 7.1 CH Windows ®  Vista Premium Level HD Audio (VIA ®  VT1708S Audio Codec)
  • On-Board LAN:
    •  PCIE x1 Gigabit LAN 10/100/1000 Mb/s
    •  Realtek RTL8111DL
    •  Supports Wake-On-LAN
    •  Supports PXE
  • Form Factor/Dimensions:
    •  ATX Form Factor: 12.0-in x 8.0-in, 30.5 cm x 20.3 cm
  • Hardware Monitoring:
    • CPU Temperature Sensing
    • Chassis Temperature Sensing
    • CPU/Chassis/Power Fan Tachometer
    • CPU Quiet Fan
    • Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
  • Accessories:
    • Quick Installation Guide, Support CD, I/O Shield
    •  ATA 133 Cable
    •  1 x SATA Data Cable
  • BIOS:
    • 4Mb AMI BIOS
    •  AMI Legal BIOS
    •  Supports "Plug and Play"
    •  ACPI 1.1 Compliance Wake Up Events
    •  Supports jumperfree
    •  SMBIOS 2.3.1 Support
    •  CPU, DRAM, NB, SB, VTT Voltage Multi-adjustment
    •  Supports Smart BIOS
